| Engine |
|
| Type |
Water/oil-cooled 4-cylinder 4-stroke in-line engine, four titanium valves per cylinder, two overhead camshafts |
| Bore x stroke |
80 mm x 49.7 mm |
| Capacity |
999 cc |
| Rated output |
142 kW (193 bhp) at 13.000 rpm |
| Max. torque |
112 Nm at 9.750 rpm |
| Compression ratio |
13.0 : 1 |
| Mixture control / engine management |
Electronic injection, digital engine electronics with integrated knock control (BMS-KP) |
| Emission control |
2 closed-loop 3-way catalytic converters, EU-3 norm with electronically controlled interference pipe and acoustic valves |
| Performance / fuel consumption |
|
| Maximum speed |
over 200 km/h |
| Fuel consumption per 100 km at constant 90 km/h |
5.7 l |
| Fuel consumption per 100 km at constant 120 km/h |
5.9 l |
| Fuel type |
Super (premium) unleaded, octane number 95 – 98 (RON) (knock control; rated output at 98 RON) |
| Electrical system |
|
| Alternator |
Three-phase alternator 350 W |
| Battery |
12 V / 10 Ah, maintenance-free |
| Power transmission |
|
| Clutch |
Multiplate clutch in oil bath, anti-hopping clutch, mechanically controlled |
| Gearbox |
Constant-mesh 6-speed gearbox, straight-toothed |
| Drive |
Chain |
| Chassis / brakes |
|
| Frame |
Aluminium composite bridge frame, partially self-supporting engine |
| Front wheel location / suspension |
Upside-down telescopic fork Ø 46 mm, compression and rebound stage adjustable |
| Rear wheel location / suspension |
Aluminium 2-sided swing arm, compression and rebound damping, high and low speed adjustable |
| Suspension travel front / rear |
120 mm / 130 mm |
| Wheelbase |
1417 mm |
| Castor |
98.5 mm |
| Steering head angle |
65,99° |
| Wheels |
Aluminium cast wheels |
| Rim, front |
3.50 x 17″ |
| Rim, rear |
6.00 x 17“ |
| Tyres, front |
120/70 ZR 17 |
| Tyres, rear |
190/55 ZR 17 |
| Brake, front |
twin disc brake, floating brake calipers, 4-piston fixed caliper, diameter 320 mm, 5 mm thick |
| Brake, rear |
Single disc brake, single piston floating caliper, diameter 220 mm, 5 mm thick |
| ABS |
Standard |
| Dimensions / weights |
|
| Length |
2.056 mm |
| Width (incl. mirrors) |
826 mm |
| Height (excl. mirrors) |
1.138 mm |
| Seat height, unladen weight |
820 mm |
| Inner leg curve, unladen weight |
1810 mm |
| Unladen weight, road ready, fully fuelled 1) |
202 kg (204.5 kg incl. Race ABS) |
| Dry weight 2) |
178 kg |
| Permitted total weight |
405 kg |
| Payload (with standard equipment) |
203 kg |
| Usable tank volume |
17.5 l |
| Reserve |
approx. 4 l |
